Eighteen Sound 8MB500-8 18sound 8 Mid Bass/8ohm/400w

• "SPECIFICATIONS || * Conforms to PowersoftTM iPal standards || * 94.2 dB SPL 1W / 1m average sensitivity || * 135mm (5.3-in) split winding. four layer ISV aluminum voice coil || * 3600 W program power handling || * Triple Silicon Spider (TSS) for improved excursion control || * Aluminum demodulating ring (SDR) for lower distortion || * Nominal Diameter 200 mm (8 in) || * Rated Impedance 8 Ohm || * AES Power 280 W || * Program Power 400 W || * Peak Power 800 W || "
• "SPECIFICATIONS || * Sensitivity 95 dB || * Frequency Range 60 - 4500 Hz * Power Compression @-10dB 0.5 dB || * Power Compression @-3dB 1.4 dB || * Power Compression @@Full Power 2.3 dB || * Max Recomm. Frequency 3000 Hz || * Recomm. Enclosure Volume 10 -40 It. || (0.35 - 1.41 cuff) || * Minimum Impedance 5.8 Ohm at 25 DegreesC || * Max Peak To Peak Excursion 19 mm (0.75 in) * Voice Coil Diameter 51 mm (2 in) || * Voice Coil winding material aluminum || "
• "SPECIFICATIONS : * Voice Coil winding material aluminum * Suspension Triple-roll. || Polycoton * Cone Curvilinear. Treated cellulose || * THIELE SMALL PARAMETERS * Fs 74 Hz || * Re 5.1 Ohm || * Sd 0.023 sq.mt. (35.65 sq.in.) || * Qms 2.66 || * Qes 0.51 || * Qts 0.43 * Vas 21.5 It. (0.76 cult) || * Mms 17 gr. (0.04 lb) || * 131 9.0 Tm || * Linear Mathematical Xmax +/- 6 mm (+/- 0.24 in) || * Le (1kHz) 0.60 mH || * Ref. Efficiency 1 W@1 m (half space) 94.4 dB || "
• "SPECIFICATIONS : * Overall diameter 210 mm (8.27 in) || * N.of mounting holes and bolt 6 || * Mounting holes diameter : 0.23 in || * Bolt circle diameter : 7.68 - 7.80 in || * Front mount baffle cutout diameter : 7.32 in || * Rear mount baffle cutout diameter : 724 in || * Total depth : 3.92 in || * Flange and gasket thickness 14.5 mm (0.57 in) || * Net weight 3.4 kg (7.5 lb) * Shipping weight 3.72 kg (8.22 lb) || * CardBoard Packaging dimensions : 9.25 x 9.25 x 5.91 in || "
• The 8M400 is a high power, high output, 200mm(8in) mid-range for high level professional use. The excellent sound quality has been achieved as a result of extensive research on mid frequencies intelligibility. The 8M400 has been designed for use as a midrange in both horn and direct radiation,closer or reflex enclosures, as small as 3 lt. The curvilinear cone,made w/a high damping wood pulp, has been designed to achieve the best possible linearity within its frequency range. ||

• Brand: Eighteen Sound
• Model Name: 8MB500-8
• Unit Count: 1.0 Count
• Included Components: 18 Sound 8MB500-8 8-inch Mid Bass Range
• Model Number: 8MB500-8
• Number of Items: 1
• Product Dimensions: 9.25"D x 5.91"W x 9.25"H
• Item Weight: 8.22 Pounds
• Special Feature: Bass Boost
• Recommended Uses For Product: For Surround Sound Systems
• Connectivity Technology: Auxiliary
• Mounting Type: Ceiling Mount
• Speaker Type: Coaxial

"The 8M400 is a high power, high output, 200mm(8in) mid-range for high level professional use. || The excellent sound quality has been achieved as a result of extensive research on mid frequencies intelligibility. || The 8M400 has been designed for use as a midrange in both horn and direct radiation,closer or reflex enclosures, as small as 3 lt. || The curvilinear cone,made w/a high damping wood pulp, has been designed to achieve the best possible linearity within its || frequency range. || The in-house developed cone treatment is a humidity repellent & also dampens the bell mode resonance significantly. || The 51mm (2in) ISV aluminum voice coil assembly is wound on a strong fiberglass former to improve force transmission & power || handling. || ISV technology is based on a high strength fiberglass former w/half the coil wound on the outside & half on the inside &...

• "SPECIFICATIONS Conforms to PowersoftTM iPal standards 94.2 dB SPL 1W / 1m average sensitivity 135mm 5.3-in split winding. four layer ISV aluminum voice coil 3600 W program power handling Triple Silicon Spider TSS for improved excursion control Aluminum demodulating ring SDR for lower distortion Nominal Diameter 200 mm 8 in Rated Impedance 8 Ohm AES Power 280 W Program Power 400 W Peak Power 800 W "
• "SPECIFICATIONS Sensitivity 95 dB Frequency Range 60 - 4500 Hz Power Compression -10dB 0.5 dB Power Compression -3dB 1.4 dB Power Compression Full Power 2.3 dB Max Recomm. Frequency 3000 Hz Recomm. Enclosure Volume 10 -40 It. 0.35 - 1.41 cuff Minimum Impedance 5.8 Ohm at 25 DegreesC Max Peak To Peak Excursion 19 mm 0.75 in Voice Coil Diameter 51 mm 2 in Voice Coil winding material aluminum "
• "SPECIFICATIONS : Voice Coil winding material aluminum Suspension Triple-roll. Polycoton Cone Curvilinear. Treated cellulose THIELE SMALL PARAMETERS Fs 74 Hz Re 5.1 Ohm Sd 0.023 sq.mt. 35.65 sq.in. Qms 2.66 Qes 0.51 Qts 0.43 Vas 21.5 It. 0.76 cult Mms 17 gr. 0.04 lb 131 9.0 Tm Linear Mathematical Xmax +/- 6 mm +/- 0.24 in Le 1kHz 0.60 mH Ref. Efficiency 1 W1 m half space 94.4 dB "
• "SPECIFICATIONS : Overall diameter 210 mm 8.27 in N.of mounting holes and bolt 6 Mounting holes diameter : 0.23 in Bolt circle diameter : 7.68 - 7.80 in Front mount baffle cutout diameter : 7.32 in Rear mount baffle cutout diameter : 724 in Total depth : 3.92 in Flange and gasket thickness 14.5 mm 0.57 in Net weight 3.4 kg 7.5 lb Shipping weight 3.72 kg 8.22 lb CardBoard Packaging dimensions : 9.25 x 9.25 x 5.91 in "
• The 8M400 is a high power, high output, 200mm8in mid-range for high level professional use. The excellent sound quality has been achieved as a result of extensive research on mid frequencies intelligibility. The 8M400 has been designed for use as a midrange in both horn and direct radiation,closer or reflex enclosures, as small as 3 lt. The curvilinear cone,made w/a high damping wood pulp, has been designed to achieve the best possible linearity within its frequency range.
